PRODUCT NORA

NORA - 1812 Ø 230

Information request
Code
Colours

  • White X=2

  • Black X=3

  • Silver X=4

  • Quality marking (CE)


    Marcatura CE

    All the products are in compliance to EN 60598-1 and part two applicable standards and to EMC applicable standards. The CE marking, applied on the products, certify their conformity with the European directives: 73/23 CEE, 93/68 CE, 2006/95/CE, 2014/35/UE (Low Voltage Directive). 89/336 CEE, 93/68 CE, 2004/108/CE, 2014/30/UE (Electromagnetic Compatibility Directive).

  • CL class of electrical insulation

    Classification on the basis of the class of electrical insulation.


    Classe II

    Electrical device with double insulation. Need not be connected to the ground circuit of the main electrical system.

  • IP Protection index

    The degree of protection of light fixtures is indicated by the letters IP (international protection) followed by two figures, the first of which indicates the index of protection againt the penetration of solid bodies and the second of liquids. For example: IP54 indicates that the device has an index of protection 5 against the penetration of solids and 4 against the penetration of water.


    IP65

    Protection against solids - First IP figure
    6 Sealed against dust
    Protection against liquids - Second IP figure
    5 Protected against jets of water

Energy class:
1812.19X
This product contains an energy efficiency class (C) light source that complies with Regulation (EU) No 2019/2015

1812.17X
This product contains an energy efficiency class (D) light source that complies with Regulation (EU) No 2019/2015

Recessed ceiling version

Single power supply cables input

LED:
The luminaire needs a remote power supplier (supplied)

The luminaire needs a remote power supply (supplied IP20)

On request

On request

Only IP20 on request

Impact Energy (J):
0,7

Product data sheet

NORA

1812 Ø 230

The luminaire is provided with aluminium reflector

Code Light source Power Voltage Lum.
Flux *		 Socket Colour
Temperature		 Surface
temperature		 CEI
installation zone **		 Beam angle Light data Technical
drawing		                  Notes
1812.17.36X LED COB 37W 5020 lm 3000 K 36° With IP20 remote driver
1812.17X LED COB 37W 5020 lm 3000 K 90° With IP20 remote driver
1812.19.36X LED COB 37W 5190 lm 4000 K 36° With IP20 remote driver
1812.19X LED COB 37W 5190 lm 4000 K 90° With IP20 remote driver
Codice
specifico		 Fotometria
2065.660 Zip - 175 MB
2065.670 Zip - 175 MB

view     not available

* Lumen rating is related to the flux emitted by the LED module and not to the flux emitted by the appliance

** Standard CEI EN 60598-2-13 for ground recessed luminaires

Information request

Standard CEI EN 60598-2-13 for ground recessed luminaires

The meaning of numbering in the catalogue besides of the lamp rating of the ground recessed luminaires is derived from the “GUIDE TO GOOD INSTALLATION PRACTICE” in the annex A of the EN 60598-2-13. Installer is strongly required to consult and take into account that standard as well as the electrical installation of building applicable and in force standards.

Not driveover

Not driveover luminaire.

Not walkover

Not walkover luminaire.

✕

recessed / NORA
